DF10 1000V 1A Full Wave Bridge Rectifier

DF10 1000V 1A Full Wave Bridge Rectifier

The DF10 1000V 1A Full Wave Bridge Rectifier converts alternating current (AC) to direct current (DC). This component provides full-wave rectification. It has a peak reverse voltage (Vrrm) of 1000V. The average forward rectified current (Io) is 1.5A. It delivers stable DC output. The design is compact. This rectifier is suitable for power supply units and battery chargers. It is also used in general-purpose rectification.

Specifications:

• Peak Reverse Voltage (Vrrm): 1000V
• Max. RMS Bridge Voltage (Vrms): 700V
• Max. DC Blocking Voltage (Vdc): 1000V
• Av. Forward Rectified Current (Io): 1.5A
• Maximum Reverse Current (Ir): 5µA
• Forward Volt Drop per Element (Vf): 1.1V
• Power Dissipation (Pd): 3.1W

Key features and benefits:

• Peak Reverse Voltage (Vrrm): 1000V
• Full-wave rectification
• Compact mini component design
• Forward voltage drop per element (Vf): 1.1V
• Average forward rectified current (Io): 1.5A
• Power dissipation (Pd): 3.1W
• Reverse leakage current (Ir): 5µA

Applications:

• Power Supply Units (PSUs)
• Battery Chargers
• AC-DC Converters
• General Purpose Rectification
• Electronic Hobby Projects
• Industrial Control Systems

Frequently Asked Questions:

Q: What is the maximum AC input voltage for this rectifier?
A: The maximum RMS bridge voltage (Vrms) is 700V.

Q: Can this DF10 rectifier be used in a 1A continuous application?
A: The average forward rectified current (Io) is 1.5A, which supports 1A continuous operation.

Q: What is the output polarity of this full-wave bridge rectifier?
A: Full-wave bridge rectifiers provide a DC output with a designated positive (+) and negative (-) terminal. Refer to the component's markings for specific pinout.

Q: What is the forward voltage drop across this rectifier?
A: The forward voltage drop per element (Vf) is 1.1V.

Q: What is the maximum DC blocking voltage?
A: The maximum DC blocking voltage (Vdc) is 1000V.

Package Includes:

*Image shown is a representation only.

Note: Contact sales(at)electroncomponents.com for bulk enquiry & get best price!
