Digital Multimeter - H 9A : True RMS Capacitance Amp Freq Temp. (BEETECH) [Original]

  • Product Code: TAM_H-9A_BT
  • Availability: In Stock
  • ₹2,202.54
  • ₹1,999.00 (+ GST)


  • Shipping Charges Start from Rs.49*
  • Fast Order Processing <24hr
  • Shipment using reputed courier with 90% delivery in 1 - 3 working days
  • All order with GST invoice (B2B: 100% cliam GST credit input tax)

Digital Multimeter - H-9A TRMS - High quality [Free shipping]

Features

  • Low battery indication & Auto power off
  • Audible continuity
  • Overload protection
  • Frequency measurement
  • Capacitance Measurement
  • Temperature Measurement
  • TRUE RMS(sinusoidal waveform RMS calibration)
  • Auto power off if unused after 15 minutes

Specifications:

Refer: user manual for technical specification

DC Volts

Input impedance: 10MΩ

Overload protection: DC/AC peak value 1000V.

Range Resolution Accuracy
600mV 0.1mV ± 0.5% of rdg ± -1 digit
6V 1mV ± 0.5% of rdg ± 1 digit
60V 10mV ± 0.5% of rdg ± 1 digit
600V 100mV ± 0.5% of rdg ± 1 digit
1000V 1V ± 0.8% of rdg ± 2 digits

AC Volts

Input impedance: 10MΩ at all ranges.
Frequency Response: 10Hz - 1KHz (10Hz-400Hz Requency for square wave accuracy).
Overload Protection:
- 200mV: max. 15 seconds at a voltage of 250V AC
- all other ranges: 1000V AC or 1000V DC.

Range Resolution Accuracy
600 mV 0.1mV ± 1.2% of rdg ± 3 digits
6V 1 mV ± 0.8% of rdg ± 3 digits
60V 10 mV ± 0.8% of rdg ± 3 digits
600V 100 mV ± 0.8% of rdg ± 3 digits
700V 1V ± 1.2% of rdg ± 3 digits

DC Amps

Overload protection: 1A / 250V fuse
The 10A range with fuse. Maximum input current: 10 A for 15 seconds.

Range Resolution Accuracy
600µA 0.1µA ± 0.8% of rdg ± 1 digit
6000µA 1µA ± 0.8% of rdg ± 1 digit
60mA 0.01µA ±1.5% of rdg ± 5 digit
600mA 0.1mA ± 1.5% of rdg ± 5 digits
6A 1mA ± 2.0% of rdg ± 5 digits
10A 10mA ± 2.0% of rdg ± 5 digits

AC Amps

Overload protection: 1A / 250V fuse
The 10A range is fused. Maximum input current: 10 A for 10 seconds.

Range Resolution Accuracy
600µA 0.1µA ± 1.0% of rdg ± 5 digits
6000µA 1µA ± 1.0% of rdg ± 5 digits
60mA 0.01mA ± 1.8% of rdg ± 5 digits
600mA 0.1mA ± 1.8% of rdg ± 5 digits
6A 1mA ± 3.0% of rdg ± 5 digits
10A 10mA ± 3.0% of rdg ± 5 digits



Resistance (Ohms)

Range Resolution Accuracy
600Ω 0,1Ω ± 0.8% of rdg ± 3 digits
6kΩ ± 0.8% of rdg ± 1 digits
60 kΩ 10Ω ± 0.8% of rdg ± 1 digits
600 kΩ 100Ω ± 0.8% of rdg ± 1 digits
6MΩ 1kΩ ± 0.8% of rdg ± 1 digits
60MΩ 10kΩ ± 2% of rdg ± 5 digits

Capacitance

Range Resolution Accuracy
10nF 0.001nF ± 2.5% of rdg ± 5 digits
100nF 0.01nF ± 2.5% of rdg ± 5 digits
1µF 0.1nF ± 2.5% of rdg ± 5 digits
10µF 1nF ± 2.5% of rdg ± 5 digits
100µF 10nF ± 2.5% of rdg ± 5 digits
1000µF 100nF ± 2.5% of rdg ± 5 digits
10mF 1uF ± 5% of rdg ± 5 digits

Frequency

Range Resolution Accuracy
10kHz 0.01Hz ± 0.5% of rdg ± 3 digits
100Hz 0.1Hz ± 0.5% of rdg ± 3 digits
100KHz 100Hz ± 0.5% of rdg ± 3 digits
10MHz 10k Hz ± 0.5% of rdg ± 3 digits

Temperature

"K" type thermocouple

Range Resolution Accuracy
-30°C - 400°C 1°C ± 0.75% of rdg ± 3 digits
400°C-1000°C 1°C ± 1.5% of rdg ± 15 digits

Diode and conductivity test

Diode test forward current: ~ 2mA.
Voltage: ~ 3.2V
The built-in buzzer will sound, if the resistance under test is less than about 30 ohms.

* Image shown is a representation only.
