5pcs : PG-7 PG Cable Gland - Polyamide (Pg 7) [Grey] IP68 Water proof [High Quality]

PG-7 Polyamide Cable Gland, IP68, Grey, 5-Pack

The PG-7 Polyamide Cable Gland is supplied as a 5-pack. It is constructed from Nylon 66 (Polyamide). Each gland has an IP68 rating, indicating complete dust sealing and water resistance. The glands provide strain relief for cables. They are designed for secure mounting into pre-drilled holes. The glands are UL-standard compliant. They support a minimum cable diameter of 3mm and a maximum of 6.5mm. The grey finish allows integration into various electrical setups. These glands maintain wiring system integrity in indoor and outdoor environments.

Specifications:

• Thread Size: PG 7
• Material: Nylon 66 (Polyamide)
• IP Rating: IP68
• Colour: Grey
• Minimum Cable Diameter: 3mm
• Maximum Cable Diameter: 6.5mm
• Recommended Tap Hole Drill Bit: 11mm (7/16")
• Recommended Pass Hole Drill Bit: 12mm (15/32")
• Standards Met: UL 94 V-2

Key features and benefits:

• IP68 rating for dust and water resistance
• Strain relief for cable protection
• Nylon 66 (Polyamide) construction
• Includes locknut for mounting
• UL Standard compliant
• Rated for indoor and outdoor environments
• Supports cable diameters from 3mm to 6.5mm

Applications:

• Electrical enclosures and control panels
• Industrial machinery and automation systems
• Telecommunications and networking equipment
• Outdoor lighting and security installations
• Marine and submersible equipment

Frequently Asked Questions:

Q: What is the IP68 rating for this cable gland?
A: The IP68 rating indicates complete dust sealing and resistance to continuous immersion in water under specified conditions.

Q: What is the cable diameter range supported by the PG-7 gland?
A: The PG-7 cable gland supports a minimum cable diameter of 3mm and a maximum cable diameter of 6.5mm.

Q: What material is used in the construction of these cable glands?
A: These cable glands are constructed from Nylon 66 (Polyamide).

Package Includes:

*Image shown is a representation only.
