TP5100 4.2v and 8.4v Dual One/Two Battery Protection Board

TP5100 4.2V/8.4V Dual Li-ion Battery Charger & Protection Module

The TP5100 is a battery charging and protection module. It supports both single-cell (4.2V) and dual-cell (8.4V) lithium-ion batteries. This board utilizes advanced switching technology for power conversion. Intelligent charging management includes automatic voltage detection. Comprehensive protection mechanisms safeguard batteries against overcharge, overcurrent, and short circuit. These features extend battery operational life and prevent damage. The TP5100 provides a charging solution for various battery-powered applications.

Specifications:

• Module Type: Li-ion Battery Charger & Protection Board
• Chipset: TP5100
• Supported Battery Type: Lithium-ion (Li-ion)
• Single Cell Charging Voltage: 4.2V
• Dual Cell Charging Voltage: 8.4V
• Charging Technology: Advanced Switching Technology
• Charging Management: Intelligent with Automatic Voltage Detection
• Protection Features: Overcharge, Overcurrent, Short Circuit

Key features and benefits:

• Supports single-cell (4.2V) and dual-cell (8.4V) Li-ion batteries
• Advanced switching technology for stable and efficient power conversion
• Intelligent charging management with automatic voltage detection
• Comprehensive overcharge protection
• Integrated overcurrent protection
• Built-in short circuit protection
• Extends battery operational life
• Prevents battery damage

Applications:

• DIY electronics projects
• Portable power banks
• IoT (Internet of Things) devices
• General portable electronics
• Solar charging setups

Frequently Asked Questions:

Q: What input voltage is required for the TP5100 module?
A: The description does not specify the input voltage range. Refer to the TP5100 datasheet for detailed input voltage requirements.

Q: Can this module charge NiMH or NiCd batteries?
A: No, the TP5100 module is designed specifically for Lithium-ion (Li-ion) batteries, supporting 4.2V and 8.4V configurations.

Q: How do I select between 4.2V and 8.4V charging modes?
A: The module features automatic voltage detection for optimal performance based on the connected battery configuration.

Q: Does this board include reverse polarity protection for the battery connection?
A: The description lists overcharge, overcurrent, and short circuit protection. Reverse polarity protection is not explicitly stated. Consult the TP5100 datasheet for full protection details.

Q: What is the maximum charging current supported by the TP5100?
A: The provided description does not specify the maximum charging current. Refer to the TP5100 datasheet for current specifications.

Package Includes:

*Image shown is a representation only.

Note: Contact sales(at)electroncomponents.com for bulk enquiry & get best price!
