5A Fuse DIP Mounted Miniature Square Slow Blow Micro Fuse 300V - Radial Type

5A DIP Mounted Miniature Square Slow Blow Micro Fuse 300V - Radial

Introducing the 5A DIP Mounted Miniature Square Slow Blow Micro Fuse, engineered for superior circuit protection. This radial-type fuse is designed to safeguard sensitive electronic components from overcurrents. Its compact square body is perfect for high-density PCB layouts, optimizing space. Featuring a slow-blow characteristic, it effectively handles temporary inrush currents without nuisance tripping. Rated at 300V, it's compatible with a wide range of AC applications. This miniature fuse ensures reliable, long-term performance in demanding environments. It's an essential component for robust power management and system integrity.

Specifications:

• Rated Current: 5 Amps
• Voltage Rating: 300V AC
• Fuse Type: Slow Blow / Time Delay
• Mounting Style: DIP / Radial Leaded
• Body Dimensions: 8mm (L) × 3mm (W)
• Lead Pitch: 5mm
• Breaking Capacity: 25A at 300V AC
• Operating Temp Range: -55°C to +125°C
• Case Style: Miniature Square Fuse
• Compliance: RoHS

Key features and benefits:

• 5A current rating for reliable medium-load circuit protection.
• 300V AC voltage rating, compatible with standard AC applications.
• Slow blow (time-delay) characteristic tolerates temporary inrush currents.
• Miniature 8x3mm square body, ideal for high-density PCB designs.
• Radial leaded design for easy through-hole mounting with a 5mm pitch.
• High breaking capacity of 25A at 300V AC ensures robust safety.
• RoHS compliant for environmental safety and lead-free operation.

Applications:

• Power supplies
• Consumer electronics
• Industrial control systems
• LED drivers
• HVAC controls

Package Includes:

*Image shown is a representation only.
