Servo Motor - VTS-05B [Vigor Original - High quality]

This is a Vigor VTS05B servo motor. It is very small, and offers huge power for its size. This servo has the dimensions - 22.5 x 12.8 x 23.3mm, weighs only 8g and develops a stall torque of more than 0.6 kg.cm . The servo comes with 3 different horns with mounting holes. The servo comes with an unmatched build quality from Vigor with guarantied reliability.

It comes in a standard 3 pin connector for simple & easy control.

Specifications & Feature
  • Small, light and efficient
  • Comes with 3 different horns - Cross, Circular and Single Sided
  • Simple typical 3 pin interface - +V, GND and Signal
  • Operating Voltage: 4.8V DC - 6 VDC
  • Output Angle: ~170°
  • Stall Torque : > 0.6 kg.cm ( 11.11 oz.in ) at 4.8V
  • Operating Speed: 0.09 sec / 60º at 4.8V
  • Size : 22.5 x 12.8 x 23.3mm ( 0.88 x 0.5 x 0.92in )
  • Weight: 8 g ( 0.28 oz )
  • Cable: 250mm long, 28AWG (Connector for FUTABA or JR style)

*Image shown is a representation only.
